iFlight XING 1303 Micro Motor - 5000KV

Description

The iFlight XING 1303 is a lightweight, high-performance motor built for micro drones. With a 5000KV rating and 3–4S support, it delivers responsive throttle performance. Featuring N52H curved magnets, single-strand copper windings, NSK bearings, and a durable unibell design, it offers smooth operation, excellent efficiency, and long-lasting durability—ideal for micro drones.

Be sure to browse the rest of our iFlight products and vast motor selection.

Features

• Single-Strand Copper Windings
• Durable Unibell Construction
• Tight magnet Air Gap
• Lightweight Design

• High-Efficiency

Specifications

• Winding: Single-strand copper winding
• Mounting Holes: 9 × 9mm, Φ2mm
• Shaft Protruding Length: 4mm
• Interphase Resistance: 386mΩ
• Dimensions: Φ17.58 × 11mm
• Weight (including wire): 6.5g
• Shaft Diameter: 1.5mm
• Magnet: N52H Curved
• Configuration: 9N12P
• Max Wattage: 98.1W
• Peak Current: 6.13A
• Input Voltage: 3–4S
• Bearing Type: NSK
• Model: XING 1303
• KV: 5000KV

Includes

• 1x iFlight XING 1303 Micro Motor - 5000KV
• 1x Hardware Kit
