Foxeer ELRS Lite 2.4GHz Receiver - Ceramic Antenna

Foxeer ELRS Lite 2.4GHz Receiver - Ceramic Antenna

$19.49
$19.49
In stock
In stock
Add To Wishlist
View full details

Details

Description

Another addition to our evergrowing ELRS receiver line up!
This tiny and lightweight ELRS receiver from Foxeer features an onboard ceramic antenna making it very easy to fit in pretty much any size frame you build.

Check out all our receivers, and our entire Foxeer line-up!

Specifications

  • Processor: ESP8285+SX1280
  • Work Frequency: 2400GHz-2500GHz
  • Flash Frequency: 25~500Hz
  • SMD Ceramic antenna
  • FW Version: 3.0.1
  • Firmware Target: Foxeer 2.4GHz RX
  • Indicator: RGB LED
  • input Voltage: 5V
  • Weight: 0.5g
  • Dimension: 10.6mmx11.5mm

Includes

  • 1 x Foxeer ELRS Lite 2.4GHz Receiver - Ceramic SMD Antenna

More Info

  • SKU: FOXE-MR1693
  • Barcode: 691023501119


Overall rating: 5.0 / 5 from 11 reviews.

AI Generated Review Summary

Summary topics

Review topics: ["range","receiver"].

Review highlights

Reviews

Works great

"I don't fly long range only close proximity. These have not failed me yet in the range I fly. Have several of these as well as radiomaster. I like the fact this one does not have the ceramic tower to possibly break off. I tuck them into the canopy on my racerx twigs."

— Chris C. (5/5)

Great for racing

"Light weight, antenna built in, an absolute must for serious racers!"

— Jason D. (5/5)

Nice receiver

"Small, lightweight, and gets the job done."

— Mason N. (5/5)

It works ok

"It works ok. I haven't range tested it but it works for what I need it for which is just flying at a local park"

— Isham P. (5/5)

Works as it should Using

"Works as it should Using it for race quad"

— Daniel M. (5/5)

Awesome little receivers

"Awesome little receivers"

— Joseph M. (5/5)

Space Saver

"Amazing how receiver technology has been able to get such a small format with the range from ELRS. You can tuck this receiver anywhere from these small toothpick quads and make a quad look clean."

— Teeravat V. (5/5)

Foxeer has the best diagrams

"This is great for saving space and weight"

— Nikolai K. (5/5)

Awesome!

"Little Giant!!!"

— Jerald T. (5/5)

Solid reciever

"Comes with wire leads soldered on. Just hook it up to your fc and you’re good to go. Form factor is tiny. Highly recommend for sub 250g or any build with limited space."

— Chris B. (5/5)
