Description

The AOS RC UL7 V5 Frame Kit is the next evolution of the UL7, purpose-built for long-range FPV pilots who demand maximum performance, strength, and efficiency. Featuring an ultra-light yet ultra-stiff structure, a durable 7075 aluminum camera cage, and the patent-pending AOS X-Cell anti-vibration mount, this 7-inch frame is engineered to deliver smooth, jello-free footage and rock-solid handling.

Be sure to browse the rest of our AOS RC products and DJI compatible frames, electronics and accessories.

Features

• Ultra-light, ultra-stiff arm design
• AOS X-Cell anti-vibration mount
• 155° wide FPV field of view
• 7075 aluminum camera cage
• Flexible stack mounting
• 14mm camera support
• Broad VTX support

Specifications

• Product Name: AOS UL7 V5 Frame Kit
• Frame wheelbase: 312mm
• Frame Dimension: 232 x 190 x 29 mm
• Arm Thickness: 3mm
• Top Plate Thickness: 2mm
• Bottom Plate Thickness: 2mm
• Side Plate Thickness: 2mm
• Max Flight Stack Height: 25mm
• Max VTX Height: 25mm
• Flight Stack Mounting: 20 x 20 Φ3mm / 30 x 30 Φ3mm
• VTX Mounting: 20 x 20 Φ2mm / 25.5 x 25.5 Φ2mm / 30 x 30 Φ3mm
• Motor Mounting: 16 x 16mm / 19 x 19mm -φ3
• Weight: 230g
• Compatibility: DJI O4 Air Unit Pro/DJI O3 Air Unit/HD Vista/BLITZ Whoop 1.6W VTX

Includes

• 1x AOS UL7 V5 Frame Kit
• 1x TPU Parts
• 1x Screw Bag
