Description

The AOS RC 7 V5 Frame Kit is the next evolution of the legendary AOS 7, preserving its ultra-stiff and durable geometry while introducing powerful new features for long-range and cinematic FPV. With its rugged 7075 aluminum camera cage, patent-pending AOS X-Cell anti-vibration system, and extensive stack/VTX compatibility, the AOS 7 V5 is engineered for elite performance and easy building.

Be sure to browse the rest of our AOS RC products and DJI compatible frames, electronics and accessories.

Features

• Ultra-durable 7075 aluminum camera cage
• AOS X-Cell anti-vibration mount
• Retains proven AOS geometry
• Broad FPV compatibility
• Flexible stack mounting
• User-friendly build
• VTX-ready

Specifications

• Product Name: AOS 7 V5 Frame Kit
• Frame wheelbase: 313mm
• Frame Dimension: L254 x W184 x H36 mm
• Arm Thickness: 8mm
• Top Plate Thickness: 2mm
• Bottom Plate Thickness: 2.5mm
• Upper Plate Thickness: 2mm
• Flight Stack Mounting: 20 x 20 Φ3mm / 30 x 30 Φ3mm
• VTX Mounting: 20 x 20 Φ2mm / 25.5 x 25.5 Φ2mm / 30 x 30 Φ3mm
• Motor Mounting: 19 x 19mm -φ3
• Weight: 325g
• Compatibility: DJI O4 Air Unit Pro/DJI O3 Air Unit/HD Vista/BLITZ Whoop 1.6W VTX

Includes

• 1x AOS 7 V5 Frame Kit
• 1x TPU Parts
• 4x Motor Wire Shield Tube
• 1x Screw Bag
• 2x Battery Strap
