ToolkitRC M8AC 600W 20A 1-8S AC/DC Smart Charger - XT60

Description

The ToolkitRC M8AC is a 600W 20A charger with AC/DC input! It supports a variety of battery types, all selectable through the big 2.4″ IPS LCD display. It’s built for performance and has a 65W USB-C port. Beyond charging, it functions as a PWM, PPM, and SBUS signal tester. Keep your drone batteries and accessories in top charging shape!

Check out our other Battery Chargers and Accessories, and all our ToolkitRC products!

Features

• Advanced Balance Charging
• Wide Battery Compatibility
• Signal Testing & Generation
• High-Powered Charging
• Compact & Efficient
• 2.4" IPS LCD Screen
• Discharge Modes
• USB-C Port (65W)
• AC/DC Input

Specifications

Output

• Power: 0.5-15A @ 1-35V (Mode: CC + CV)
• SBUS: 880us-2200us × 16CH @ 74Hz
• PWM: 500us-2500us @ 20-1000Hz
• PPM: 880us-2200us × 8CH @ 50Hz

Measurer

• Internal Resistance: 0.1mΩ-99mΩ @ 1-8S
• SBUS: 880us-2200us × 16CH @ 20-100Hz
• PPM: 880us-2200us × 8CH @ 20-50Hz
• PWM: 880us-2200us @ 20-400Hz
• Voltage: 1.0V-5.0V @ 1-8S

Discharging Power

• USB-C: MAX 20.0V @ 65W (Upgrade)
• 0.1-20A @ 300W (Recycle Mode)
• 0.1-3A @ 20W (Normal Mode)

Battery Type

• LiPo, LiHV, LiFe, Li-Ion, LTO @ 1-8S
• Charging Power: 0.1-20A @ 600W
• Balance Current: 1000mA @ 4.2V
• Balance Accuracy: <0.005V
• NiMH @ 1-20S
• Pb @ 1-12S

General

• Product Size: 108 × 113 × 62mm
• Packing Size: 136 × 153 × 67mm
• LCD: IPS 2.4″ LCD, 320 × 240px
• Packaging Weight: 600g
• Product Weight: 500g

Charger

• Input Voltage:
• AC 100-240V @ MAX 2.5A
• DC 7-35V @ MAX 25A

Includes

• 1x ToolkitRC M8AC 600W 20A 1-8S AC/DC Smart Charger - XT60
• 1x Screen Protector
• 1x AC Input Cable
• 1x Quick Manual
• 1x USB Cable
