Description
The AOS UL7 EVO is an ultralight 7-inch FPV frame designed rigidity and flight performance. Its vertical truss arm structure stiffness while keeping weight down. Featuring a soft-mounted FPV camera, ND filter support for DJI O3, and compatibility with 14-20mm FPV cameras (with a 3D-printed mount for 14mm), this frame is built for freestyle, long-range, and high-speed chasing. Push your limits with the AOS UL7 EVO.
Check out all of our 7" frames and our selection of iFlight gear!
Features
- Compatible with 14-20mm FPV Cameras
- Ultralight & Stiff Vertical Truss Arms
- Supports ND Filters with DJI O3
- Revolutionary Frame Design
- Versatile Flight Capabilities
- Optimized for 7” Propellers
- Soft-Mounted FPV Camera
Specifications
- Flight Stack Mounting: 20×20 Φ2mm / 25.5×25.5 Φ2mm / 30×30 Φ3mm
- VTX Mounting: 20×20 Φ2mm / 25.5×25.5 Φ2mm / 30×30 Φ3mm
- Frame Dimensions: L190 × W262 × H29mm
- Motor Mounting: 16×16mm / 19×19mm
- Product Name: AOS UL7 EVO Frame Kit
- Max Flight Stack Height: 25mm
- Bottom Plate Thickness: 2mm
- Frame Wheelbase: 312mm
- Side Plate Thickness: 2mm
- Top Plate Thickness: 2mm
- Arm Thickness: 2.5mm
- Weight: 233g
- Due to manufacturing processes, the thickness of this products may have a standard manufacturing tolerance of ±0.2mm. The size of the hole may have a standard manufacturing tolerance of ±0.1mm.
Includes
- 1x AOS RC UL7 EVO Frame Kit
- 1x Hardware Kit
More Information:
- SKU: 22876
- Barcode: 723326371325
